Cisco N3K-C3064PQ-10GE-B Nexus 3064-E 48-Port 10Gb SFP+ Data Center Switch with Reverse Airflow

Cisco N3K-C3064PQ-10GE-B Nexus 3064-E 48-Port 10Gb SFP+ Data Center Switch with Reverse Airflow

Ονομασία μάρκας: Cisco
Αριθμός μοντέλου: N3K-C3064PQ-10GE-B
Τροποποιημένο: 1
τιμή: Διαπραγματεύσιμα
Λεπτομέρειες
Τόπος καταγωγής:
OEM
Συσκευασία λεπτομέρειες:
Νέο πρωτότυπο κουτί
Περιγραφή του προϊόντος
Cisco N3K-C3064PQ-10GE-B Nexus 3064-E 48-Port 10Gb SFP+ Data Center Switch with Reverse Airflow

The Cisco N3K-C3064PQ-10GE Nexus 3064-E switch is a single-rack unit Ethernet switch designed for high-performance data center environments. This enterprise-grade switching solution features VLAN support, comprehensive storm control mechanisms, Weighted Random Early Detection (WRED), and Rapid Spanning Tree Protocol (RSTP) support.

The switch provides wire-rate Layer 2 and Layer 3 switching and supports both standard and reverse airflow schemes. It comes standard with dual AC power supplies, port-side exhaust "B" type airflow, and a rack kit. Standard fans (port-side intake) are available upon request.

Key Specifications
Part Number N3K-C3064PQ-10GE
Device Type Switch - 48 Ports - L3 - Managed
Dimensions Rack Mount - 1U (17.3" x 19.9" x 1.7")
Performance Switching Capacity: 1.28 Tbps | Forwarding Performance: 960 Mpps
Capacity Virtual Interfaces (VLANs): 4096 | MSTP Instances: 64 | Rapid Spanning Tree Protocol Example: 512
Advanced Features
  • VLAN support with 4096 virtual interfaces
  • Comprehensive storm control (broadcast, multicast, unicast)
  • Weighted Random Early Detection (WRED)
  • Rapid Spanning Tree Protocol (RSTP) and Multiple Spanning Tree Protocol (MSTP)
  • DHCP snooping and Quality of Service (QoS)
  • Jumbo Frame support and Virtual Router Forwarding Lite (VRF-Lite)
  • Fast VLAN Spanning Tree Enhanced Version (PVRST+)
  • Syslog support for comprehensive logging
Interface Configuration
  • 48 SFP+ Ports for 10Gb connectivity
  • 4 QSFP+ Ports for high-speed uplinks
  • 1 console interface (RJ-45) for management
  • 2 10/100/1000Base-T interfaces (RJ-45) for management
  • 1 USB port for additional connectivity
Routing Protocols
  • IGMPv2
  • IGMPv3
Compliance Standards

CISPR 22 Class A, BSMI CNS 13438 Class A, CISPR 24, EN 61000-3-2, VCCI Class A ITE, EN 61000-3-3, EN55024, EN55022 Class A, AS/NZS 60950-1, ICES-003 Class A, RoHS, FCC CFR47 Part 15, EN300-386, IEC 60950-1, EN 60950-1, UL 60950-1 Second Edition, CSA C22.2 No. 60950-1, GB 4943

Enterprise Performance: The Cisco N3K-C3064PQ-10GE-B Nexus 3064-E delivers reliable end-to-end connectivity for mid-size data centers, enterprise campus core networks, and high-density server deployments. Built on Cisco's resilient switching architecture, it ensures low-latency data transmission critical for cloud computing, big data analysis, and enterprise business systems.

Intelligent Management: Powered by Cisco NX-OS operating system with comprehensive traffic scheduling, access control, and quality of service optimization. Supports automated network deployment and dynamic configuration adjustment for improved operational efficiency.

Optimized Design: Reverse airflow design enables efficient heat dissipation in diverse data center cabinet deployments. Redundant hardware protection mechanisms enhance reliability and minimize unexpected downtime.
